Rotabroach Element-75 Magnetic Drill

  • For heavy duty operations the ‘Element 75’ is a must for drilling larger holes.
  • Compact, durable and more portable than other larger machines.
  • Suitable for drilling up to 75mm diameter by 75mm depth.
  • The ‘Element 75’ offers forward and reverse functionality.
  • The ‘Element 75’ can be supplied as a swivel base or a non-swivel option.
  • The Element range uses a unique dual motor protection system prolonging the machines life and preventing unwanted wear.
Category:
Brands:: ROTABROACH
Model Number Element 75/3
Motor Specification 230V 1800W
No Load RPM Low Gear: 70 -180 RPM

High Gear: 200-500 RPM
Max Hole Cutting Capacity 75 x 75mm Deep – 26mm with MT Drill
Overall Dimension (mm) Height: 545mm / Width: 230mm with Capstan / Length: 460mm with Guard
Machine Weight 23.5kg
Magnetic Adhesion 18,500N
Safety Features Cutsmart™ Technology / Fixed Guard / Magnetic Detection / Mechanical Clutch
